Mach3 Serial Port Plugin Container

by

USB to Parallel Converter




Summary
PC Operating System
 Windows2000/Xp/Vista/Windows7
Supporting Software Mach3 R3.042.040 version or latest versions
Software Plugin function (UsbMove(V2.0.1.2).zip)Download (Updated on 1 June 2011)
Acceptable Axis Control number
 4 Axes (Different embedded software, same card)
Input signal channels
 16 (TTL signal)
Output signal channels
 8 (TTL signal) Available to provide DC10V-DC24V output voltage by external power supply
Spindle speed control output signal
1 PWM channel for controlling either VFD inverter and E240 controller.
Hand Wheel Function
 1 Channel
Tool Auto-Checking Instrument 1 Tool Auto-Checking Instrument channel
Spindle speed measurement
1 sensor channel
External software control
2 Knob for control either Feed Rate, Spindle Speed or Slow Jog Rate of the
Mach 3 software ( EXT0 is installed, EXT1 is installed by user)
ManualDownload
Out Dimension 85.1mm * 148.6mm
Electronic Diagram
PDF Version
OtherNot support Slave Axis function

Dimension


Main features

1. Fully support all Mach3 software versions, included the latest version of the Mach3 R3.042.040.

2. Support Windows OS，included the Windows7 OS.

3. Do not need to install any USB drivers and external power supply，the card can be used immediately after connecting the USB cable.

4. An isolated power supply is included, thus, external power supply is not requested for simple connection. Furthermore, external power supply can also be applied for enhancing the functions of the USB card.

5. Full support USB hot-swappable, monitoring the USB connection status any time. So, if USB cable is disconnected during the Mach3 operation, the card is still working after USB cable is connected.


6. Support controlling 4 axes CNC system at the same time.
7. 200KHz output, it is suitable for the control system of the servo / stepping motor system.

8. Support tool auto-checking instrument, electronic hand wheel, limit switches, emergency stop button and the software function for consuming the backlash.

9. 16 LEDs are installed in the particular input channels for indicating the status of the input channels.

10. 48M speed. The control signals generated by the USB card are isolated from the PC signals that the USB card is a real-time and stable system.

11. A LED indicator is installed that the states of the USB card can be displayed during the system operation.

12. VFD Spindle PWM output and Spindle speed sensing system，the spindle speed can be displayed on the Mach 3 interface in graphic detail.

13. Select ten 10Mhz High Speed Optocouplers and 24 Optocouplers for isolating the input/output signals and protecting the system. In addition, a completed high-cost anti-interference performance and an improved protection are provided

14. External rating knob, there are two channels for changing any two ratings including Feed Rate, Spindle Speed Rate and Jog Rate.


Video


Notes: Before you make a bid for this action, please read the following notes carefully!
  1. The total weight of your selected items may influence the final shipping cost!
  2. The shown photos and pictures in this action may be different from the actual products.
  3. An electronic manual is provided for our customers. Please contact us to take the manual!
  4. Any software is not included.
  5. For safety reason, the machine may be exploded and separated into several packages. You may need to assemble few components! If you have any problems about the packaging and assembling, please contact us before your bidding!
  6. Please contact us confirming the actual shipping cost and details before you bidding!

Price:
- USD 210 - USBP-04-001
## The prices are not included any shipping cost. Please email us for acquiring the actual shipping cost!##
Latest Update: 22 June 2011
UsbMove(V2.0.1.2).zip

If Mach3 is not configured with the correct information your TB6560 Driver board won't function. Looking at the line 'ECP Printer Port (LPT1)' tells us 2 things, in your computers BIOS the printer port is set to the ECP protocol, and, it is Port 1 (from LPT1) on the PC's serial/parallel bus.

Serial Port Pinout

  1. If Mach3 is not configured with the correct information your TB6560 Driver board won't function. Looking at the line 'ECP Printer Port (LPT1)' tells us 2 things, in your computers BIOS the printer port is set to the ECP protocol, and, it is Port 1 (from LPT1) on the PC's serial/parallel bus.
  2. Serial communication with Mach3. Out of the box Mach3 provides some limited ways of communicating with external devices over the serial port (not counting MODBUS). Under Config -> General Config you can select the baudrate and either 8-N-1 or 7-N-2.
