Creo Elements/Pro, formerly known as Pro/ENGINEER and Wildfire, is a 3DCAD, CAM, CAE, and associative solid modelling app. It is one of a suite of 10 collaborative applications that provide solid modelling, assembly modelling, 2D orthographic views, finite element analysis, direct and parametric modelling, sub-divisional and NURBSsurface modelling, and NC and tooling functionality for mechanical designers. Creo Elements/Parametric compete directly with Solidworks, CATIA, and NX/Solid Edge. It was created by Parametric Technology Corporation (PTC) and was the first of its kind to market.^[1]

The application runs on Microsoft Windows. The UNIX version was discontinued after 4.0,^[2] except x86-64 UNIX on Solaris.^[3] The name changed to Creo 1.0 after Pro/ENGINEER Wildfire 5.0 (rebranded PTC Creo Elements/Pro),^[4] took place on October 28, 2010, which coincided with PTC’s announcement of Creo, a new design software application suite.

• 2Summary of capabilities

Overview[edit]

Creo Elements/Pro (formerly Pro/ENGINEER), PTC's parametric, integrated 3D CAD/CAM/CAE solution, is used by discrete manufacturers for mechanical engineering, design and manufacturing.

Pro/ENGINEER was the industry's first rule-based constraint (sometimes called 'parametric' or 'variational') 3D CAD modeling system.^[5] The parametric modeling approach uses parameters, dimensions, features, and relationships to capture intended product behavior and create a recipe which enables design automation and the optimization of design and product development processes. This design approach is used by companies whose product strategy is family-based or platform-driven, where a prescriptive design strategy is fundamental to the success of the design process by embedding engineering constraints and relationships to quickly optimize the design, or where the resulting geometry may be complex or based upon equations. Creo Elements/Pro provides a complete set of design, analysis and manufacturing capabilities on one, integral, scalable platform. These required capabilities include Solid Modeling, Surfacing, Rendering, Data Interoperability, Routed Systems Design, Simulation, Tolerance Analysis, and NC and Tooling Design.

Musicas De Me Llueve 3 . 0

Creo Elements/Pro can be used to create a complete 3D digital model of manufactured goods. The models consist of 2D and 3D solid model data which can also be used downstream in finite element analysis, rapid prototyping, tooling design, and CNC manufacturing. All data are associative and interchangeable between the CAD, CAE and CAM modules without conversion. A product and its entire bill of materials (BOM) can be modeled accurately with fully associative engineering drawings, and revision control information. The associativity functionality in Creo Elements/Pro enables users to make changes in the design at any time during the product development process and automatically update downstream deliverables. This capability enables concurrent engineering – design, analysis and manufacturing engineers working in parallel – and streamlines product development processes.

Summary of capabilities[edit]

Creo Elements/Pro is a software application within the CAID/CAD/CAM/CAE category.

Creo Elements/Pro is a parametric, feature-based modeling architecture incorporated into a single database philosophy with rule-based design capabilities. It provides in-depth control of complex geometry, as exemplified by the trajpar parameter. The capabilities of the product can be split into the three main headings of Engineering Design, Analysis and Manufacturing. This data is then documented in a standard 2D production drawing or the 3D drawing standard ASME Y14.41-2003.

Product Design[edit]

Creo Elements/Pro offers a range of tools to enable the generation of a complete digital representation of the product being designed. In addition to the general geometry tools there is also the ability to generate geometry of other integrated design disciplines such as industrial and standard pipe work and complete wiring definitions. Tools are also available to support collaborative development.

A number of concept design tools that provide up-front Industrial Design concepts can then be used in the downstream process of engineering the product. These range from conceptual Industrial design sketches, reverse engineering with point cloud data and comprehensive free-form surface.

Analysis[edit]

Creo Elements/Pro has numerous analysis tools available and covers thermal, static, dynamic and fatigue finite element analysis along with other tools all designed to help with the development of the product. These tools include human factors, manufacturing tolerance, mould flow and design optimization. The design optimization can be used at a geometry level to obtain the optimum design dimensions and in conjunction with the finite element analysis.

Surface Modeling[edit]

Creo has a good surface modeling capabilities also. Using commands like Boundary blend and Sweep we can create surface models. Advance options like Style (Interactive Surface Design Extension - ISDX) and Freestyle ^[6] provide more capabilities to designer to create complicated models with ease.

Manufacturing

By using the fundamental abilities of the software with regards to the single data source principle, it provides a rich set of tools in the manufacturing environment in the form of tooling design and simulated CNC machining and output.

Tooling options cover specialty tools for molding, die-casting and progressive tooling design.

Release History[edit]

For the first 10 years, PTC generally released 2 versions per year, with some exceptions. The initial release (Rev 1) was in 1988.

Bebe Milo Isla Vs Isla 5 . 0

See also[edit]

Comparable Software

References[edit]

Bleach Vs Naruto 3 . 0

1. ^'PTC History - PTC'.
2. ^[1], retrieved 2011-12-06
3. ^Software Update Availability (Advanced), PTC, 2012-06-06, archived from the original on 2012-08-10, retrieved 2012-06-06
4. ^'PTC - PTC Introduces Creo Design Software'.
5. ^Horgan, Jack (2004-06-21). 'EDA & PLM?'. EDACafe.com Contributing Editor. Retrieved 2010-06-15.
6. ^'Parametric and Freestyle Surfacing - PTC'.
